These limits are designed to provide reasonable protection against harmful interference in a residential installation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

#MOULTRIE FEEDER MANUAL#

This device must accept any interference received, including interference that may cause undesired operation.įor devices approved under Part 15, the user’s manual or instruction manual for an intentional or unintentional radiator shall caution the user about changes or modifications to the device (Section 15.21).

This device may not cause harmful interference, and.

Operation is subject to the following two conditions: This device complies with part 15 of the FCC Rules. To activate the Feeder motor for a period of five seconds, fully extend the Transmitter Antenna and hold the Activation Button until the Feeder runs.

#MOULTRIE FEEDER ACTIVATOR#

If using the Feeder Activator in a metal Feeder enclosure, the Antenna Wire must be routed outside the box in an area that is not accessible by varmints. The Antenna Wire should not be folded or in contact with the motor.

Route the black Antenna Wire inside the plastic Feeder enclosure.

Position the Receiver on a clean and dry location inside the Feeder.

Remove the protective cover from the double sided tape on the back of the Receiver.

Refer back to Section B for details on connection. Pull-up on metal clip with pliers to release the wires. Open the Plastic Cover on the Connectors and carefully pry open with a screwdriver. If motor does not run, check connections to Battery and to motor as shown. Feeder motor will run for a period of five seconds. To test the Feeder Activator, stand back from the feeder and press the button on the Transmitter.

Immediately following connection of the battery, the red Status Light on the Receiver will be on solid or blinking:.Connect the Red Wires to the positive terminal (+) and the Black Wires to the negative (-) terminal. Connect the battery to the Feeder and then to the Receiver.This will prevent you from compromising the wires that run between the timer circuit board and the the motor on your feeder kit.

#MOULTRIE FEEDER INSTALL#

Use the steps from Section B1 to install the receiver wires onto these activator wires. If installing on a Moultrie feeder kit, locate the separate wires labeled “Feeder Activator Connection +/-” as shown in the photo. WIRING THE RECEIVER – MOULTRIE FEEDER KIT Repeat steps 1 through 3 for the Black Negative Wire.Close the Plastic Cover until it snaps into place. With pliers, squeeze the metal contact tab down until it is even with the surface of the plastic.If it is not identified, select either wire. The positive wire may be red in color, marked “positive”, or not identified. Slide the positive wire that runs between the Feeder’s circuit board and the motor into the side of the Connector as shown.Holding one of the provided Connectors in the orientation shown, push the Receiver’s Red Motor Wire into the rear hole until it reaches the internal stop. Disconnect the battery from the Feeder.The Feeder Activator may be used in a metal Feeder enclosure if the Antenna Wire can be routed outside the box. NOTE: On Moultrie feeder kits, there are two separate wires labeled “Feeder Activator Connection” that should be used for connection. b) The two wires that run between the feeder circuit board and the motor are accessible – enabling the connection of the Feeder Activator motor wires.a) When the battery is installed in the feeder, the positive and negative contacts are exposed and accessible enabling the connection of the Feeder Activator power wires (with alligator clips).
